HS-800 Medical Heat Sealer
For production of high quality heat seals in flexible packaging. Produces seals up to 800mm long x 10mm wide.
Precision Medical Heat Sealer for production of repeatable high quality heat seals in medical packaging, validation to ISO 11607.
Description
For production of high quality heat seals in flexible packaging. Produces seals up to 800mm long x 10mm wide.
Precision Medical Heat Sealer for production of repeatable high quality heat seals in medical packaging, validation to ISO 11607.
Features & Benefits
For production of high quality heat seals in flexible packaging. Produces seals up to 800mm long x 10mm wide.
Precision Medical Heat Sealer for production of repeatable high quality heat seals in medical packaging, validation to ISO 11607.
Technical Specifications
Models
HS-800 Single Upper jaw temperature controlled HS-800 Dual Upper & Lower jaw
temperature controlled.
Seal Width
Up to 800mm max.
Controller
Individual panel mounted controllers for temperature, pressure and dwell times.
Optional footswitch operation.
Temperature Control
Range: Ambient to 300°C, Accuracy: +/- 0.5%, Operating Accuracy: +/-2°C. User definable
alarm for over/under set level.
Pressure
Range: 0 to 100psi (6.8bar, 689Kpa), via digital pressure gauge, pressure control via
precision regulator. Accuracy +/-5%. User definable alarm for over/under set level. Supply via
clean and dry compressed airline or bottled air/nitrogen at 75 to 115psi.
Dwell Time
Range: 0.1 to 99.9 sec., Resolution 0.1 sec. Accuracy +/-5%.
Delay Time
Delay Time Range: 0.1 to 99.9 sec.
Jaw Alignment System
Jaw alignment for even closure, resulting in consistently high quality seals.
Sealing Jaws
Standard flat jaws 10mm x 800mm, constructed in aluminium with precision ground face. Lower
sealing jaw with precision ground silicone rubber face. (See options below).
Environment
5-50°C ambient operating temperature, RH 75% max (noncondensing).
Power
240V AC 50/60 Hz (110V AC available on request).
Accessories
Options
Sealing jaw dimension/profile as required (inc. Matched crimp 120° x 1.8mm pitch).
Teflon Coated Tape or Teflon Coated Jaws.
Auto Cycle runs machine continuously, with delay time between cycles.
Guillotine cutter.
Validation documentation / service.
